Input Voltage Range:230-480 VAC, 3-Phase
Auxiliary Power Supply:Yes
Nominal Input Current (AC):14 Amps
Root Means Square Input Frequency (AC):47-63 Hz
Bus Overvoltage:810Vdc
Shunt On:800Vdc
Continuous Output Power @ 480 VAC:10.0 kW
Continuous Output Power @ 230 VAC:5.0 kW
Maximum Power Loss:350W
Weight:Approximately 10.44 kg
Shock Resistance:Up to 15g at 11ms half-sine
Output Current (Intermittent):23A (0-peak)
Output Current (Continuous):46A (0-peak)
Nominal, 230Vac Input:0.5 Amps RMS
Nominal, 115Vac Input:1.0 Amps RMS
The Allen-Bradley 2098-DSD-HV100-SE is a cutting-edge servo drive designed to meet the high demands of industrial automation systems. Its robust design ensures reliability even in the most challenging environments.
Featuring a wide voltage range from 230Vac to 480 Vac, 3-phase, and a frequency range of 47 to 63 Hz, this servo drive is versatile and adaptable to various industrial applications.
Equipped with advanced technology, the 2098-DSD-HV100-SE provides precise control over motor speed, torque, and position, making it ideal for applications requiring high accuracy and efficiency.
With its internal shunt resistance of 40 ohms, the drive efficiently manages power loss, ensuring optimal performance and system stability.
The inclusion of a dedicated RS232/RS485 interface with DeviceNet support enables seamless integration with control systems, enhancing operational efficiency and connectivity within manufacturing environments.
The Allen-Bradley 2098-DSD-HV100-SE is not just about functionality; it also prioritizes safety. It adheres to international safety standards, ensuring reliable operation and reducing the risk of equipment failure.
