Rated Voltage:1200V
Rated Current:920A / 1030A
Module Type:IGBT Module
Package Configuration:Dual IGBTs in a single module
Cooling Method:Air-cooled or water-cooled
Operating Temperature Range:-40°C to +150°C
Thermal Resistance:Junction to Case: 0.12°C/W
Isolation Voltage:3000V
Switching Frequency:Up to 20kHz
Protection Features:Short circuit protection, overcurrent protection, undervoltage lockout
The Allen Bradley SK-H1-QOUT-D1K0820A series represents cutting-edge technology in IGBT modules, providing robust performance in demanding industrial environments.
These modules are built with state-of-the-art materials and advanced design techniques to ensure longevity and efficiency.
With a dual IGBT configuration rated at 920A and 1030A, they offer unparalleled power handling capability and fast switching speeds.
Designed for air-cooled systems, they minimize thermal resistance, ensuring optimal performance under varying load conditions.
Their DIP package ensures easy integration into existing systems, reducing installation time and costs.
Ideal for applications requiring high-reliability power conversion, such as renewable energy systems, industrial drives, and electric vehicle charging stations.
