3BHE021083R0101 | XVC770BE101 Digital Output Module – ABB

Product Type:Digital Output Module

Model Number:3BHE021083R0101

Sub-Type:XVC770BE101

Operating Voltage:DC 24V

Output Capacity:10A per channel

Channels:8

Response Time:≤ 1ms

Operating Temperature:-20°C to +70°C

Storage Temperature:-40°C to +85°C

Enclosure Type:IP20

Dimensions (LxWxH):125mm x 67mm x 40mm

Weight:0.15kg

Communication Interface:RS-485

    The ABB 3BHE021083R0101 Digital Output Module and XVC770BE101 are meticulously engineered to meet the stringent requirements of industrial environments. With an ultra-fast response time of ≤ 1ms, these modules ensure instantaneous output changes, enhancing system responsiveness.

    Featuring a wide operating voltage range of 24V DC, they are compatible with a broad spectrum of industrial applications. The robust current rating of 5A max allows for efficient handling of high-power loads, making them suitable for applications requiring substantial output capacity.

    The modular design ensures easy integration into existing automation systems, facilitating seamless expansion and customization. The MODBUS RTU communication interface enables simple connectivity, simplifying data exchange and control protocols.

    Engineered for reliability and durability, these modules are tested under extreme environmental conditions, ensuring they operate within a temperature range of -20°C to +70°C without compromising performance. The IP20 enclosure type provides basic protection against dust and splashes, safeguarding the internal components from external hazards.

    With a load capacitance limit of 100 μF max, these modules can handle a variety of load types efficiently, making them versatile for different industrial settings. The SPDT relay contacts offer dependable switching capabilities, ensuring reliable operation even under challenging conditions.
