GE

Model Type:High Resolution Analog

Number of Channels:2 Inputs & 2 Outputs

Input Range:-20 To 20 V

Absolute Input Voltage:Plus/Minus 7.5 VDC or 7.5 VAC RMS (Max)

Input Current:-30 To 30 MA (Max)

Output Range:-10 To 10 V – 1 LSB

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Current Rating:Backplane Current Draw: 55 MA

    This Allen Bradley 1746-NIO4V module offers unparalleled accuracy in analog signal processing, making it an essential component for complex industrial automation systems.

    With its robust design, the module is capable of handling a wide range of input voltages and currents, ensuring reliable performance in diverse operational environments.

    The dual-input feature allows for simultaneous measurement of two different signals, providing flexibility in monitoring and controlling multiple parameters.

    The high-resolution output capability ensures precise voltage control, critical for processes that require fine adjustments and sensitivity.

    Built-in overvoltage protection safeguards against electrical spikes and surges, enhancing system reliability and reducing maintenance costs.

    Its open-type enclosure facilitates easy installation and maintenance, while the status LED provides real-time feedback on module operation, enabling proactive monitoring and troubleshooting.
