Input Voltage (0-peak):230-480 Vac, Three Phase
Nominal Input Current (AC):14 Amps
Root Mean Square Input Frequency (AC):47-63 Hz
Auxiliary Power Supply:Yes
Continuous Output Power @ 480 Vac:10.0 kW
Continuous Output Power @ 230 Vac:5.0 kW
Shunt Voltage Powered On:800V
Shunt On:Enabled
DC Internal Shunt Resistance:20 Ohms
Dimensions:9.54 x 15.43 x 8.0 in (242.2 x 391.8 x 203.2 mm)
Operating Temperature Range:0 to 55 °C
Relative Humidity Range:0 to 95% non-condensing
PID Control:Variable
PWM Frequency Input:Supported
EMC Compliance:Certified
Drive Standards:Compatible with various industry standards
The Allen-Bradley 2098-DSD-HV220-SE AC Drive is engineered for seamless integration into complex industrial systems, offering enhanced control over machinery and processes.
Equipped with an internal shunt resistance of 20 Ohms, this drive ensures precise voltage regulation, crucial for high-efficiency operation in demanding environments.
With support for USB 1.0 and 2.0, the 2098-DSD-HV220-SE enables quick and easy configuration, facilitating fast setup and maintenance without the need for specialized equipment.
Operated at a temperature range of 0°C to 55°C, this drive is suitable for a wide variety of industrial applications, ensuring reliable performance year-round.
The 2098-DSD-HV220-SE AC Drive boasts a compact yet robust design, capable of handling high currents of up to 94A intermittently, and delivering continuous power outputs of 10.0 kW at 480 VAC and 5.0 kW at 230 VAC, making it ideal for heavy-duty operations.
