PILZ – PILZ Component

Type:Safety Relay

Series:PNOZ X

Model:2.1

Part Number:774306

Rating:110-120VAC

Number of Channels:11

Number of Open Contacts:6

Number of Closed Contacts:4

LED Indicators:6

Operating Temperature Range:-25°C to +60°C

Protection Class:IP20

Material:Metal Enclosure

Weight:0.3 kg

    The Pilz PNOZ X Series 2.1, Model 774306 is designed with advanced circuitry to ensure high reliability and fast response times in safety-critical applications. Its compact size and versatile connection options make it suitable for a wide range of industrial automation setups.

    Featuring 11 input channels, this module can handle various inputs from sensors and switches, providing comprehensive control over safety functions. The inclusion of 6 normally open and 4 normally closed output channels allows for flexible integration into safety circuits.

    With 6 LED indicators, the module offers clear visual feedback on the status of each channel, enhancing system monitoring and troubleshooting. The mechanical relays are known for their durability and long service life, ensuring consistent performance over time.

    Operated within a temperature range of -25°C to +60°C, the PNOZ X Series 2.1, Model 774306 is suitable for use in a variety of industrial environments. Its IP20 enclosure rating protects against dust and light splashes, ensuring reliable operation under typical factory conditions.

    The 2 x 10-pin terminal block facilitates easy connection to external devices, allowing for straightforward installation and maintenance. The overall design ensures efficient heat dissipation, contributing to the module’s longevity and robustness.
