3401 – Triconex Digital Module

Model Type:Digital Output Module

Manufacturer:Triconex

Model Number:3401

Nominal Output Voltage:24 VDC

Operational Voltage Range:15 to 30 VDC

Absolute Maximum Output Voltage:33 VDC

Absolute Maximum Reverse Input Voltage:– 0.6 VDC

Output Current:<4.8 A, self-limiting 3.0 A, typical

Degraded Mode:> 0.7 A, self-limiting 1.5 A, typical

Field Alarms:Loss of field power, output point shorted

Loop-back Thresholds:0–5 VDC = Off region, 6–14 VDC = Transition region, 15–30 VDC = On region

    The TRICONEX 3401 Digital Output Module is engineered to meet the demands of industrial automation processes with its high reliability and precision. It offers a nominal output voltage of 24 VDC, ensuring stable operation within an operational voltage range of 15 to 30 VDC. With absolute maximum output voltage up to 33 VDC, this module ensures durability under varying conditions. The 0.7 A, self-limiting to 1.5 A, making it a versatile choice for a wide range of applications. It comes equipped with built-in safety features like loss of field power detection and output point short circuit protection. The loop-back thresholds allow for precise control and monitoring of output states, enhancing system efficiency. Ideal for use in manufacturing, petrochemical, and energy sectors, the TRICONEX 3401 ensures seamless integration into existing systems, providing enhanced reliability and performance.
